Preflash tests of Kodak E100VS on M13




E100SV 30 min

E100SV 30 min with 4 Stop Preflash



Preflash tests of Kodak E100SV on M13

Telescope:

AP-130 at F/8 using Nikon 1.4x teleconverter and AP Field Flattener.
AP 600 GoTo Mount with ST-4
Film & Exposure: 1st image: Kodak E100, one 30 min exposure with Tokai LPF Filter

2nd image: Kodak E100, one 30 min exposure with Tokai LPF Filter  and Preflash at 4 stops

Raw scans (no auto adj, no curves) from SprintScan 35+ shown with Blackpoint set to 30/30/30

Location: My Driveway (Huntertown, IN),   Moderate Light Pollution
Date: June 3, 2000
Comments: There is a noticable improvment in the image depth with preflashing.  Although contrast is lower, it appears that it may reduce exposure time by at least one F stop.

The preflashing was done with a 50mm lens pointing at a white matt board under fluorescent lights.  A 1/60 exposure was made with a 4 stop increase from the measured normal f stop setting.

Although the film background appeared to be even, large stretching of the image showed a hot vertical strip.  If the astrophoto is wide field with heavy processing, a more uniform light source would be desired.



Final Note:

     The nice thing about E100SV is that anything that it records can stand quite a bit of processing.  The image below is a composite of two E100SV shots, one with and one without preflashing.




M13 Composite of two E100SV shots at 90mins, one preflashed and one normal
